AISI ASTM 316 Stainless Steel Pipe 316l Welded/Seamless Steel Pipe
Standard: GB, ASTM, JIS, SUS, DIN, EN etc
Length: 1m - 12m, or according to your requests.
Technique: Cold Rolled, Hot Rolled, Forging
Surface Processing: You can Galvanized, coated, or as your request.
Packing: Bundled, wooden box for export standard package
Delivery Time: 7-15 days or according to the order quantity or upon negotiation
Place of Origin: Jiangsu, China
| Grade | UNS No. | Old British | Euronorm | China GB | Japanese JIS | ||
| BS | EN | No. | Name | ||||
| 316L | S31600 | 316LS15 | 58E | 1.4408 | X5CrNi18-10 | 0Cr17Ni14 | SUS316L |
| 316 | S31603 | 316S12 | – | 1.4401 | X2CrNiN18-9 | 0Cr18Ni9 | SUS316 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316L | Min. Max. |
/ 0.03 |
/ 2.0 |
/ 1.0 |
/ 0.045 |
/ 0.030 |
16.00 18.00 |
2.0 3.0 | 12.00 15.00 |
/ |
| 316 | Min. Max. |
/ 0.03 |
/ 2.0 |
/ 1.0 |
/ 0.045 |
/ 0.030 |
16.00 17.00 |
2.0 3.0 |
11.00 14.00 |
/ |
| 317 | Min. Max. |
/ 0.08 |
/ 2.0 |
/ 1.0 |
/ 0.035 |
/ 0.030 |
18.00 10.00 |
3.0 4.0 |
11.00 15.00 |
/ |
| Grade | Tensile Strength (MPa) |
Yield Strength 0.2% Proof (MPa) |
Elongation (% in 50mm) |
Hardness | |
| Rockwell B (HR B) |
Brinell (HB) |
||||
| 316 | 515 | 205 | 40 | 92 | 201 |
| 316L | 515 | 205 | 40 | 90 | 187 |
| 317 | 520 | 205 | 35 | 90 | 187 |
| Specifications | ASTM A240 / ASME SA240 | ||||||
| Thickness | 0.5mm-100mm | ||||||
| Outer diameter | 10mm, 25.4mm, 38.1mm, 50.8mm, 100mm, 250mm, 300mm, 350mm, etc | ||||||
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | ||||||
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | ||||||
| Finish | Hot rolled (HR), Cold rolled Tube (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | ||||||
| Form | Round tube Square tube Rectangular tube etc. | ||||||
FAQ
Q: Where are you? Can I visit you?
A: Of course, we are in Wuxi, Jiangsu, China. You are welcome to visit our factory at any time.
Q: What are your strengths?
A: Honest enterprise, competitive prices and professional export process services.
Q: What payment methods does your company support?
A: T/T, cash, Western Union are all accepted, if you have other payments, please contact me.
Q: What is the average delivery time?
A: For samples, the delivery time is about 5-7 days.
For mass production, the delivery time is 10-25 days. In any case, we will try our best to meet your needs.
Q: What is the minimum order quantity?
A: If you want to order a small number of orders or trial orders, please feel free to contact us, we can meet your requirements.
